NEW 1- channel 12-lead Electrocardiograph ECG EKG Machine FDA/CE APPROVED
Specifications
| Restocking Fee | 20% |
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Model | ECG100G |
| Country/Region Of Manufacture | China |
| MPN | ECG100G |
| Brand | Contec |
| UPC | Does not apply |
1- channel 12-lead Electrocardiograph ECG EKG Machine USPS Fast CE Features: 12-lead simultaneous standard resting ECGOne-touch operationConcept of floating input circuit meets IEC safety standardHigh-resolution thermal printing array systemFrequency response is as high as 150HzCapable of printing continuously on channel trace and annotations including lead mark and parameter such as sensitivity, paper speed and filter operation statusHigh resolution digital filter inhibits baseline drift without affecting ECG waveformRechargeable battery supporting more than 50 patient examinations Specification: Safety standardIEC60601-1 class I, type CFInput circuitFloating; Protection against Defibrillator effectLeadStandard 12 Leads, Lead change automaticallyPatient current leakage3.2seconds CMRR>80dB >100dB (with filter)EMG filter 35Hz (-3dB) / 25Hz (-3dB) Sensitivity1/2, 1, 2 (cm/mV), Conversion Deviation≤5%Recording system Thermal-array 8 dots/mm ( vertical ) 16 dots/mm ( horizontal, 25mm/sec )Paper speed 25, 50mm/s±3%Recording paper 50mm,20m, high-speed rollInput circuit current≤50nA Power supplyAC: 220V / 110V, 50/60HzDC: 12V rechargeable battery Skin voltage tolerance±300mVNoise level<15uVp-pDimensions 310×230×70mm Dimension of packing400×280×160mmWeight2.75kg Standard Packing list: ItemNo.ContentQtyRemarkStandard Configuration1Electrocardiograph1 2Banana type ECG cable 1 3Chest electrodes6 4Limb electrodes4 5Ground wire for earthing1 6Power cable1 7Manual 1 8Packing list1 9Paper Roll1 The following FDA Disclaimer is required for all eBay listing in Healthcare category and is included for REFERENCE:The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, We will verify your status as an authorized purchaser of this item before shipping of the item.
