8-32 Phillips Oval Head Machine Screws Stainless Steel Countersunk All Sizes
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 60 Days |
| Brand | Fastenere |
| Fastener Type | Machine Screw |
| Drive Type | Phillips |
| Head Style | Oval Head |
| MPN | POMS18855832 |
| Grade | 18-8 |
| Material | Stainless Steel |
| Thread Diameter (in.) | 0.164in |
| Drive Style | Phillips |
| Thread Size Base | 8-32 |
8-32 Phillips Oval Head Machine Screws Stainless Steel Oval heads have a low dome and are tapered for countersinking. Machine Screws are a straight shanked fastener designed to be used in a hole that is pre tapped or a clear hole with a nut on the opposite side. Stainless Steel Machine Screws are used in applications which require general atmospheric corrosion resistance, refrigeration equipment, and food processing machinery. These screws have an approximate Rockwell hardness of B85 - B95 and a minimum Tensile Strength of 80,000 PSI General Product Information Oval Head Screws Length is Measured from the top of the Head to the Tip Head Style : Oval Drive Style : Phillips Drive Size : #2 Thread : 8-32 Material : Stainless Steel 18-8 Overall Length : Select Length in Drop Down Menu Quantity of Fasteners in Package : Select Package Quantity in Drop Down Detailed Product Information: Head Diameter : 0.312" Head Height : 0.152" Countersink Angle : 82 Degree Thread Diameter : 0.164" Threads Per Inch (TPI) : 32 Coarse or Fine Thread : UNC Coarse Thread Coverage : Fully Threaded Key Notes: Machine screws are uniformly threaded screws of 1/4" nominal diameter or less that is designed to be threaded into uniformly threaded nuts or threaded holes in the parts they are intended to fasten. Machine screws primary tightening is accomplished by turning the head of the screw. With a bolt, the primary tightening procedure might be accomplished by turning the nut. Oval is a countersunk style head with a cone shaped bearing surface and a rounded top that is preferred over flat heads in a conical application or one that a more decorated finish is desired. Phillips drive is a cross head design and is the most commonly used type in America. Phillips is often criticized for its tendency to cam out at lower torque levels but this was actually a deliberate feature of the design, for the purpose of assembling aluminum aircraft without overtightening the fasteners. The vast majority of stainless steel fasteners are produced with metals from the austenitic family. Their high levels of chromium and nickel provide tough corrosion resistance and the ability to withstand considerable physical strain without fracturing, albeit at a higher cost than the martensitic varieties. Made of stainless steel grade 18-8 which offers a high level of chemical and corrosion resistance and strength that will out perform and out last all zinc plated fasteners for years with out the need to perform costly and time consuming maintenance. Shipping: All orders placed before 3:30 pm EST Will Ship Same Day Tracking is provided on ALL Orders Priority Mail Shipping service is offered at a discount of only $3.95 UPS Ground UPS Next Day Air is available, Please inquire for pricing Returns : ALL returns are accepted if returned within 60 days. Money Back or exchange guaranteed. NO Restocking Fees. For YOU, we constantly strive to find ways of improving our performance.
